FLYX™ provides maximum flexibility for a wide range of slab formwork requirements. The main beam of this system is adjustable, FLYX™ is therefore the ideal solution for complicated slab plans or integrated down stand beams and forming operations in confined spaces.
FLYX™ provides maximum flexibility for a wide range of slab formwork requirements. The main beam of this system is adjustable, FLYX™ is therefore the ideal solution for complicated slab plans or integrated down stand beams and forming operations in confined spaces.
| 1. | Light unit weight | Light unit weight facilitates for workers to carry materials. simplify for transportation and cost saving. |
| 2. | Adjustable main beam | The main beam is adjustable to suit different sized rooms with strong versatility. |
| 3. | Learnable | The same beam connection method as traditional timbers enables workers to adjust themselves to make products more effectively. |
| 4. | Sub Beam Nailed | Timbers can be filled into the sub beam through the bottom. Then workers can nail plywood to the sub beam. |
| 5. | Robust | High quality cold rolled steel Q235 grade, surface treatment is finished by electrophoretic painted of better corrosion resistance. |
| 6. | High Reuse Time | Replacing traditional timbers, it can be recycle- used for more than 300 times. |
| 1# Adjustable Main Beam | 2.68-4.39m | 20.1kgs |
| 2# Adjustable Main Beam | 2.28-3.68m | 17.1kgs |
| 3# Adjustable Main Beam | 1.77-2.88m | 13.5kgs |
| 4# Adjustable Main Beam | 1.17-1.78m | 8.75kgs |
| 1# Cross Beam | 2.79m | 7.5kgs |
| 2# Cross Beam | 2.44m | 6.62kgs |
| 3# Cross Beam | 2.10m | 6kgs |
| 4# Cross Beam | 1.57m | 4.3kgs |
